Touch pads have multi-level password protection to prevent usage by unauthorized personnel or program changes by anyone other than the supervisor.EZ-Pad Plus touch pad is 12 V DC with a 3-line LCD display.Touch pad is flush mounted.Conduit, wiring, and programming is the responsibility of the electrical contractor.One-year warranty.
|
|
7 Inch color touch screen user interface.Touch pad is flush mounted.EZ Pad 3.0 uses ethernet communications between relay boxes and touch screens.Conduit, wiring, and programming is the responsibility of the electrical contractor.UL Listed.One-year warranty.
Supporting Documents
Return to Top
|
|
Includes Smart Gym Processor Assembly, one or more Smart Gym Touch Screens or Wi-Fi tablet kits, and one or more Smart Gym Relay Panel.Smart gym touch panel operates with Ethernet communications, and relay panels communicate on 24 Volt current.
|
|
One transmitter (503061) and one handheld receiver (503060) are required to have an operable system (each sold separately).One 503060 EZ-Power Receiver is required for each motor to be operated and supports low-voltage supplemental key switch (sold separately).
Transmitter (503061) is powered by a standard 9-volt battery and can individually operate up to 99 transmitters.
|
|
Momentary contact, 3 position (on-off-on) flush mount key switches available up to 7 ganged switches.Ganged switches require switch boxes that measure 3" (76 mm) h x 1-7/8" (48 mm) w, times the number of switches and 2-½" (64 mm) d.UL recognized switches rated at 25 amps, up to 277 volts, and 1 hp at 125 volts.
Supporting Documents
Return to Top
|
|
Plug kit includes: one four-prong NEMA L14-20P twist lock ground plug, one matching NEMA L14-20 twist lock grounded receptacle, and one matching ½” (13 mm) deep cover for a 4” (101 mm) electrical box. All wiring and electrical components are to be in accordance with local codes, and as per manufacturers installation instructions. All conduits, wiring, and other electrical components are to be supplied by the electrical contractor.
|
|
Increase awareness, the Audible Alarm Kit for Backstop or Divider Curtain Winch alerts people of overhead equipment operation in a gymnasium.
Audible alarm assembly consists of 4” x 4” (102 mm x 102 mm) electrical steel box with twist lock receptacle, 80 decibel beeper and 5’ (1.52 m) long cord with twist lock plug. Four-prong twist lock plug to be connected to the winch.Provided with twist lock receptacle on 4” (102 mm) square cover for connection to building power source.
|
|
|
